Waterproof Breathable Fabrics: Product Modification and Recent Developments (Part-2)

Shailja Sharma
M. Tech. Scholar
Department of Textile Technology,
NIT Jalandhar, India
Cell: +91- 8872-431933
Email: shailjadrs@gmail.com

Previous Part

3.2 Smart Breathable Fabrics
Smart Fabrics and Interactive Textiles are defined as having an in-built ability to respond to external stimuli, including electrical, mechanical, thermal, chemical or magnetic. Current smart textile systems aiming to reduce the discomfort caused by moving between hot and cold environments generally rely on temperature as a stimulus [20]. Temperature sensitive polymers can be used in membranes and coatings in combination with fabric which gives waterproof breathability in which WVP changes with change in temperature. To design fabrics which can use humidity as a trigger to react to changes in the micro-climate in order to keep the wearer dryer for longer and get dry quicker can be more comfortable to wear [11].

3.2.1 TS-PU (Temperature Sensitive Polyurethane)
Temperature-sensitive polyurethane (TS-PU) is one novel type of smart polymer. The water vapour permeability (WVP) of its membrane could undergo a significant increase as temperature increases within a predetermined temperature range. Such smart textiles would not only be waterproof at any temperature, but also provide variable breathability in response to the climate temperature [17].

3.2.2 Temperature-Sensitive Copolymer
A smart breathable cotton fabrics using a temperature-sensitive copolymer - poly (N-tertbutylacrylamide-ran-acrylamide:: 27: 73) was developed by Save et al.

Recipe Used:

Copolymer(aq.) -20 wt%
1,2,3,4-butanetetracarboxylic acid (cross-linker)-50 mol%
Sodium hypophosphite (catalyst)-0.5 wt%

Followed by drying (120°C, 5 min) and curing (200°C, 5 min).

The coatings after integration to the cotton substrate retained temperature-sensitive swelling behaviour and showed a transition in the temperature range of 15-40Â°C. The coated fabrics showed a temperature-responsive water vapour transmission rate (WVTR) [6].

3.2.3 HPMC
Hydroxypropyl methyl cellulose (HPMC) is an intensively investigated temperature-sensitive polymer which has a simultaneously hydrophilic and hydrophobic structure and demonstrates a low critical solution temperature (LCST) at about 55.65 °C. In an aqueous solution, the macromolecular chains of HPMC experience reversible solubility and exhibit a significant hydration-dehydration change in response to temperature stimulus. These polymers have both hydrophilic and hydrophobic groups in their structure. Below LCST, the hydrophilic interactions dominate and polymer becomes soluble in water, while above this temperature hydrophobic interactions dominate and polymer becomes insoluble in water. The gel change shape by swelling in water below transition temperature and de-swells above transition temperature [17].

The temperature responsive smart breathable behaviour of the HPMC coated fabric was studied in a recent research.

DSC Curve for HPMC Polymer

Recipe Used:

HPMC(aq.) -10 wt%
Citric acid(cross-linker)-5 wt%
Sodium carbonate (catalyst)-0.5 wt%

And then followed by drying and curing.

The coatings after integration to the cotton substrate retained temperature-sensitive swelling behaviour and showed a transition in the temperature range of 30-40°C.The coated fabric is exposed to external temperature, it will display swelling/shrinkage or hydration/dehydration properties, and cause changes in the water vapour transmission rates (WVTR), permeance and permeability of the fabrics [17].

3.3 Fabrics based on Biomimetics
Biomimicry or biomimetics- is a new way to think of how we may be producing new materials in the future. Biomimicry is derived from the Greek word „bio‟ –meaning life and „mimetic‟ meaning „mimic.‟ Biomimetics is the science of applying nature's principles to human engineering and design [19]. Biomimetics is the mimicking of biological mechanisms, with modification, to produce useful artificial items [2]. And biomimetics clothes are those which mimic the wonders of biological world and perform more effectively

3.3.1 The Pine Cone Effect
Humidity-responsive adaptive textiles respond to levels of humidity in the micro-climate, so that breathability improves as the material begins to saturate [18]. The fabrics based on pine cone can be used for a more effective waterproof breathability. Pine cone opens and closes its spines according to the weather, If it's going to rain, the spines close up to protect the seeds inside and if it's going to stay dry, the spines open up to improve the chances of the seeds escaping [13]. Researchers at England's Bath University and the London College of Fashion are trying to design biomimetics clothes that could work the same way. The fabric could be made with an outer layer of tiny spikes, only 1/200th of a millimetre wide. When it's hot, the spikes would open up to let out the heat, cooling you down. When it's cold, the spikes would flatten back down to trap air and provide more effective insulation [13].

Open Spines of a Pine Cone

Closed Spines of a Pine Cone

NIKE MARCO REACT
Nike introduced similar concept to produce its „Macro React‟ range with a Fish-scale Pattern. It was first worn by tennis star Maria Sharapova at US Open 2006 and later by Roger Federer at Wimbledon.

When someone wear this clothing, upon perspiration, the flaps in the fabric swings open to release heat and moisture to keep one dry and cool. The same clothing is made way for golf dresses [16].

INOTEK Fibres
Also the introduction of INOTEK Fibres developed by MMT Textiles, which works on pine cone effect, has brought a new revolution in the field of waterproof breathability. The fibres alleviate the feeling of dampness by increasing the permeability of yarns and textiles as moisture builds up around them. The manufacturers in the field of sports clothing, base layers, underwear, socks and bedding fabrics can bring new products that has improved comfort which can be delivered by keeping them dryer for longer and getting them dry quicker in extreme conditions. The U.S. Army Natick Soldier Research, Development and Engineering Centre in Massachusetts have tested a range of textiles using INOTEK patented fibres and validated all the resulting data. They verified its performance via a series of tests carried out on 100% INOTEK fibres, its blend with natural fibres like Merino wool and commercial fibres like Tencel, all the test samples showed significantly improvement in permeability at 98% Rh against relevant test and control samples. The breathability of INOTEK textiles improves gradually from the first point of elevated relative humidity up to optimum performance at the point of saturation [20].

INOTEK fibres work just opposite to the wool fibres. As the material starts absorbing moisture the fibres start to close (mimicking the pine cone) and reduce in volume causing yarn to thin three-dimensionally in the cross-section. Microscopic air pockets are opened in the material and this increases its breathability. In contrast to pure wool, an INOTEK/wool blended yarn can reduce its thickness by up to 10% of its original width in damp conditions. The reactive response to humidity is also reversible. INOTEK fibres revert back to their original state in dry conditions, reducing air permeability and increasing insulation of the textile as in case of pine cone[20].

INOTEK fibres can find application not only in apparel sector but also in health and hygiene sector such as bedding, where more efficient moisture management would be of huge benefit and wound dressing, where this unique breathable technology could control moisture levels beneath the dressing, enhancing comfort whilst offering the same level of protection from infection etc [20].

3.3.2 Transpiration within a Leaf Effect

Transpiration is a process that involves loss of water vapour through the stomata of plants. The loss of water vapour from the plant cools down the plant when the weather is very hot. When the plant loses water through transpiration from the leaves, water from the stem and roots moves upward, or is `pulled', into the leaves.

Open and closed tomato

AZKO NOBEL’s Stomatex

The clothing is made of neoprene fabric along with foam insulation which has tiny hole like dome, as like the transpiration process within a leaf, which provides a controlled release of water vapour to make the clothing comfortable. Stomatex is claimed to respond to the level of activity by pumping faster as more heat is produced, returning to a more passive state when the wearer is at rest. Stomatex is used in conjunction with Sympatex, Akzo Nobel‟s waterproof breathable membrane, to produce a breathable waterproof insulating barrier for use in clothing and footwear. The manufacturer claimed it as „the most comfortable clothing and footwear systems in the world today‟ [2] [12] [16].

4. Conclusion:
The technology has witnessed significant developments in the field of waterproof breathable fabrics in recent times from bi-components to smart breathable fabrics including biomimetic clothes and there is a long way to go in the future. The development of INOTEK fibres has brought a revolution in the field as they will improve the standard of products in quality and functionality. Among all the products being used in this field the biomimetic clothing can be proved best effective.The scopes are unlimited and resources are infinite. Any change in the technology and methods can lead to the development in the field of Waterproof Breathable Fabrics which can be used effectively and efficiently in near future.

5. References:

5.1 Publications:

Arunangshu Mukhopadhyay and Vinay Midha (2008), “A Review on Designing Waterproof Breathable Fabrics Part I: Fundamental Principles and Designing Aspects of Breathable Fabrics”, Journal of Industrial Textiles; 37(3):225-262.
A R Horrocks and S C Anand, Handbook of Technical Textiles:“Chapter 12 Waterproof Breathable Fabrics”, 1st Edition, Woodhead Publishing, New York, 2000
Ilhen Ozen (2012); “Multi-Layered Breathable Fabric Structures with Enhanced Water Resistance”; Journal of Engineered Fibers and Fabrics; Volume 7, Issue 4; 63-69.
Devanand Uttam (2013); “Active Sportswear Fabrics”; International Journal of IT, Engineering and Applied Sciences Research; Volume 2, Issue 1; 34-40
Han-Yong Jeon, Woven Fabrics: “Chapter 6 Polyester Microfilament Woven Fabrics”, 1st Edition, InTech Publication, 2012
Save.N.S., Jassal.M., and Agrawal.A.K..; Journal of Industrial Textiles, January 1, 2005; 34(3): 139 - 155

5.2 Websites

http://www.marmot.com/
http://www.asfgroup.com/
http://www.patagonia.com/
http://www.thenorthface.com/
http://www.inotechtextiles.com/
http://www.stomatex.com/

5.3 Online Articles

Biomimetics Clothes by Chris Woodford. http://www.explainthatstuff.com/biomimeticclothing.html
An Overview of Waterproof Breathable Fabrics by Ariful Hasan, Al-amin Sohag, Lutfur Rahman, Uzzal Hossain, NM Walid. /search?q=waterproof-breathable-fabrics-part-1
Waterproof Breathable Fabrics- Explained by Matt Fuller and Dr Mark Taylor. http://www.ukclimbing.com/articles/page.php?id=4556
Biomimetics: Engineering New Textile by Md. Abbas Uddin Shiyak http://www.textiletoday.com.bd/magazine/30
Application of smart polymers to textile By S. Ariharasudhan, R. P.Sundaram http://www.fibre2fashion.com/industry-article/2/132/application-of-smart-polymers-to-textile8.asp
Biomimetic fibres mimic pine cones in responce to humidity http://www.newmaterials.com/News_Detail_Biomimetic_fibres_mimic_pine_cones_in_responce_to_humidity_12895.asp#ixzz3JJJ2QUYU
New 'Smart-fabric' inspired by pine cones http://www.gizmag.com/go/3515/
New biomimetic fibres to revolutionize textile sector http://www.fibre2fashion.com/news/textile-news/newsdetails.aspx?news_id=120745&page=1
